| GHB102 |
Front Hub Outer Bearing |
2 |
□ Missing from Parts Book Index. |
 |
|
|
0 |
| GHS132 |
Seal |
2 |
□ Missing from Parts Book Index. |
|
|
|
0 |
| 59177 |
Cap |
2 |
|
|
|
|
0 |
| LN2211 |
Castle Nut 1/4" UNF x 3/4" AF x 0.440"/0.430" |
2 |
□ Parts book Possib. Wrong. May be 1/2" UNF
|
|
|
|
1 |
| PC20 |
Split (Cotter) Pin 1/8" Diam x 1" Long |
2 |
|
|
|
|
1 |
| 132666 |
Washer |
2 |
|
|
|
|
0 |
| 136860 |
Stud |
8 |
□ Safety Item
|
|
|
|
0 |
| 151081 |
Hub Assembly |
2 |
□ Safety Item
|
|
|
|
0 |
| GHB101 |
Rear Hub Inner Bearing. (Timken L44649 Inner & L44610 Outer or similar)
Timken |
2 |
|
|
|
|
0 |
| 133539 |
Shield |
2 |
|
|
|
|
0 |
| 154474 |
Stub Axle |
2 |
|
|
|
|
0 |
| 209344 |
Vertical Link |
2 |
|
|
|
|
0 |
| YN2911 |
Full Nyloc Nut - 1/2" UNF 3/4" Across Flats 0.603" Thick |
2 |
|
|
|
|
1 |
| 159514 |
Bolt |
2 |
|
|
|
|
0 |
| WL210 |
Washer - Lock 7/16" ID x 0.78" O/D |
2 |
|
|
|
|
1 |
| 215210 |
Steering Tie Rod Lever RH |
1 |
□ Right Hand
|
|
|
RH |
0 |
| 215211 |
Steering Tie Rod Lever LH |
1 |
□ Left Hand
|
|
|
LH |
0 |
Next Page: 04-39
